IP68 Waterproof Metal circular Connector, cable mounted str plug Fischers S 1031A019-130

Name: IP68 Waterproof Metal circular Connector cable mounted str plug Fischers S 1031A019130
Brand: RAYMO
Price: 1 USD

China IP68 Waterproof Metal circular Connector, cable mounted str plug Fischers S 1031A019-130 wholesale

Brand Name : RAYMO

Model Number : RM-S 1031A019-130

Certification : ROHS2.0, REACH, CE, SGS, ISO9001:2015

Place of Origin : SHENZHEN, CHINA

MOQ : 1PC

Price : Negotiable

Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram

Supply Ability : 50000pcs per week

Delivery Time : 3-5 working days

Packaging Details : PE BAG+ CARTON

Shell size : 0F(102), 1F(103), AF(1031), 2F(104), 3F(105)

Insulator Material : PEEK, PPS

Gender : Female

Pin : 2-19pins

IP Rating : IP68

Contact Now

Description of Connector

RM-F Series Core series IP68 waterproof Metal circular push pull connectors

Part No.:	S.103A062-140 / RM-WSO-1F1S-P12JS52
Prct Description:	1F(=103) size,S model cable mounted straight plug connector, 12pin male contact, code 1, black-color chrome plated shell in brass, 52 size cable collet for 4.2-5.2mm

Key Features

IP68 ranking
3 different code
Miniature circular connector
Miniest circular connectors
High corrosion resistance
Hermetic receptacle structure can be suitable for equipment requiring air

Technical Characteristics

Temperature Range	- 65° C, +200° C	Resistance to vibrations	15 g [10 Hz - 2000 Hz]
Shell Material	Brass with chrome plated	Humidity	up to 95% at 60° C/140F
Shock Resistance	100 g [ 6 ms]	Salt spray corrosion test	>144 hr
Climatical Category	50/175/21	Shielding (min)	> 95 dB [ at 10 MHz], > 80 dB [ at 1 GHz]
IP Rating	IP 68	Endurance(shell)	≥5000 mating cycles

Applications

Aviation
Communications
Industrial Control
Information Systems
Military
Test and Measurement
Data Acquisition
Data Transfer Equipment
Sensor Systems Instrumentation
Analysis Application

Prct Picture

IP68 Waterproof Metal circular Connector, cable mounted str plug Fischers S 1031A019-130

Our Exhibition

2020.11	Electrnica Munich, Germany
2020.9	Testing Expo, Shanghai
2019 9.24-9.26	Testing Expo, Shanghai
2018 11.12-11.15	Electronica Munich, Germany
2017 9.11-9.16	NAB Show,Netherlands
2016 4.11-4.15	HK Fair
2015 10.2-10.7	ICEEB, Brasil
2014 10.11-10.15	HK Fair
2014 4.11-4.15	HK Fair

Our Company

SHENZHEN RAYMO ELECTRONICS TECHNOLOGY LIMITED is a manufacturer located in Shenzhen that is a leading companyin the design, manufacturing and distribution of high-performance connectors and cable assembly solutions.Known for their quality, ruggedness and excellent sealing, our prcts prove to be reliable in the most demanding environments.

IP68 Waterproof Metal circular Connector, cable mounted str plug Fischers S 1031A019-130

Why Choose US

100% compatible with lemo, , fischer connector
Help you save at least 50% cost
All the prcts we got CE, ROHS, SGS,ISO9000 certificate
Fast delivery: 2-15 working days
Cable assembly offer, help you save prction time

RFQ

1.What is your payment terms?
Raymo: 100% T/T deposit when customer place order.
2. Does your prct have any warranty?
Raymo: Yes, all of our connectors can work normally after 5000 cycles mating; our factory has instruments to tested them beforeshipping.
Damage due to misuse, treatment and unauthorized modifications and repairs are not covered by our warranty.
3. Are your company a professional manufacturer?
Raymo: Yes, we specialized in prcing circular push pull connectors and cable assembly since 2010.
4. What is the MOQ?
Raymo: No MOQ limited, small order is accepted, all is depend on customer real needs.
5. Free sample :
RAYMO: Available. Any needs, please contact us:
6. What about the delivery time?
Raymo: sample for 1-2 working days, mass prction for 5-10 working days.

If you couldn't find exact items you want,PLS kindly email us exact models you need, best price & each model specification details will be provided to you soon. Solve the original brand's high cost and long lead time!
